536417 | FESTO | Compact Cylinder AEN-25-5-A-P-A

₹ 7,015.85

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

536417

Fabricant d'équipement d'origine

FESTO

Description
Parameter Specification
Stroke 1 mm ... 25 mm
Piston diameter 25 mm
Cushioning Elastic cushioning rings/plates at both ends
Mounting position Optional
Conforms to standard ISO 21287
Design Piston
Piston rod Profile barrel
Position detection Via proximity switch
Variants
  • Improved running performance
  • Extended male piston rod thread
  • Custom thread on the piston rod
  • Extended piston rod
  • With protection against rotation
  • Heat-resistant seals max. 120°C
  • Laser etched rating plate
  • Pulling
Piston rod at one end Yes
Operating pressure 0.1 MPa ... 1 MPa / 1 bar ... 10 bar
Mode of operation Pushing, Single-acting, Pulling
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20 °C ... 120 °C
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 196 N
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 246 N
Additional weight per piston rod extension of 10 mm 6 g
Additional weight per piston rod thread extension of 10 mm 4 g
Type of mounting Either:
With through-hole
Via female thread
With accessories
Pneumatic connection M5
Note on materials RoHS-compliant
Material collar screws Steel
Material cover Anodised wrought aluminium alloy
Material piston rod High-alloy steel
Material cylinder barrel Smooth-anodised wrought aluminium alloy
