SPARECRUX is NOT an authorized distributor for FESTO

536847 | FESTO | Fine Filter MS6-LFM-1/2-BUV-DA

₹ 6,545.72

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

Fabricant d'équipement d'origine

FESTO

Description
Parameter Specification
Series MS
Size 6
Design Fibre filter
Grade of filtration 1 µm
Condensate drain Fully automatic / Manual, non-detenting
Symbol 00991544
Operating pressure 0.2 MPa – 1.2 MPa2 bar – 12 bar29 psi – 174 psi
Operating medium Compressed air (ISO 8573-1:2010 [6:-:4]), Inert gases
Air purity class at output ISO 8573-1:2010: [5:-:3]
Max. standard flow rate 950 l/min
Min. standard flow rate 140 l/min
Filter efficiency 99.99%
Max. condensate volume 38 ml
Bowl guard Integrated as metal bowl
Corrosion resistance class (CRC) 2 – Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Suitable for use with food See supplementary material information
Media temperature range -10 °C to 60 °C
Ambient temperature range -10 °C to 60 °C
Storage temperature range -10 °C to 60 °C
Filter efficiency (fine particles) 99%
Residual oil content 0.5 mg/m³
Filter efficiency (oil aerosol) 90%
Differential pressure display Visual display
Type of mounting With accessories
Mounting position Vertical ±5°
Pneumatic connection (Port 1) G1/2
Pneumatic connection (Port 2) G1/2
Material (housing) Die-cast aluminium
Material (filter) Borosilicate fibre
FESTO
