SPARECRUX is NOT an authorized distributor for FESTO

543825 | FESTO | Manifold Block CPE10-PRS-1/4-6

₹ 2,172.41

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

543825

Fabricant d'équipement d'origine

FESTO

Description

Property Value
Grid dimension 16 mm
Mounting position optional
Max. number of valve positions 6
Max. number of pressure zones 2
Burst pressure 5 MPa
Burst pressure 50 bar
Burst pressure 725 psi
Operating pressure -0.09 MPa ... 1 MPa
Operating pressure -0.9 bar ... 10 bar
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Media temperature -5 °C ... 50 °C
Ambient temperature -5 °C ... 50 °C
Max. tightening torque for valve mounting 1.2 Nm
Product weight 323 g
Type of mounting (in-line valve manifold) With through-hole
Mounting method for valve Via female thread
Pneumatic connection, port 1 G1/4
Pneumatic connection, port 3 G1/4
Pneumatic connection, port 5 G1/4
Note on materials RoHS-compliant
Material manifold rail Wrought aluminium alloy
