SPARECRUX is NOT an authorized distributor for FESTO

573472 | FESTO | Solenoid Valve VUVG-S14-B52-ZT-G18-1T1L

₹ 3,924.82

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

573472

Fabricant d'équipement d'origine

FESTO

Description

Property Specification
Valve function 5/2 bistable
Type of actuation Electric
Valve size 14 mm
Standard nominal flow rate (DIN 1343) 630 l/min
Pneumatic working port G1/8
Operating voltage 24V DC
Operating pressure -0.09 MPa ... 1 MPa
Operating pressure -0.9 bar ... 10 bar
Design Piston gate valve
Approval c UL us - Recognized (OL)
Degree of protection IP65, IP67
Exhaust-air function With flow control option
Sealing principle Soft
Mounting position Optional
Manual override Detenting, Non-detenting
Type of piloting Pilot actuated
Pilot air supply External
Flow direction Reversible
Symbol 00991125
Lap Overlap
Signal status display LED
Pilot pressure 0.15 MPa ... 0.8 MPa
Pilot pressure 1.5 bar ... 8 bar
Max. switching frequency 3 Hz
Switching time reversal 9 ms
Duty cycle 100%
Max. positive test pulse with 0 signal 1600 µs
Max. negative test pulse with 1 signal 3000 µs
Characteristic coil data 22 V DC: 1.0 W
Permissible voltage fluctuations +/- 10%
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
