SPARECRUX is NOT an authorized distributor for SICK SENSORS

6021464 | SICK SENSORS | CQ35-25NNP-KC1 Capacitive Proximity Sensors

₹ 10,194.40

  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

6021464

Fabricant d'équipement d'origine

SICK SENSORS

Description

Housing Rectangular
Dimensions (W x H x D) 35 mm x 69.5 mm x 15 mm
Sensing range Sn 4 mm ... 25 mm
Safe sensing range Sa 18 mm
Installation type Non-flush
Switching frequency 50 Hz
Connection type Male connector M12, 4-pin
Switching output NPN
Switching output detail NPN
Output function Complementary
Supply voltage 10 V DC ... 36 V DC
Ripple ≤ 10 % 1)
Voltage drop ≤ 2.5 V DC 2)
Current consumption 10 mA 3)
Time delay before availability ≤ 100 ms
Hysteresis 4 % ... 20 %
Reproducibility

≤ 5 % 4)

 5)

Temperature drift (of Sr) ± 10 %
EMC According to EN 60947-5-2 6)
Continuous current Ia ≤ 200 mA



SICK SENSORS 6021464 CQ35-25NNP-KC1 Capacitive Proximity Sensors
SICK SENSORS

6021464 | SICK SENSORS | CQ35-25NNP-KC1 Capacitive Proximity Sensors

₹ 10,194.40
Housing Rectangular
Dimensions (W x H x D) 35 mm x 69.5 mm x 15 mm
Sensing range Sn 4 mm ... 25 mm
Safe sensing range Sa 18 mm
Installation type Non-flush
Switching frequency 50 Hz
Connection type Male connector M12, 4-pin
Switching output NPN
Switching output detail NPN
Output function Complementary
Supply voltage 10 V DC ... 36 V DC
Ripple ≤ 10 % 1)
Voltage drop ≤ 2.5 V DC 2)
Current consumption 10 mA 3)
Time delay before availability ≤ 100 ms
Hysteresis 4 % ... 20 %
Reproducibility

≤ 5 % 4)

 5)

Temperature drift (of Sr) ± 10 %
EMC According to EN 60947-5-2 6)
Continuous current Ia ≤ 200 mA
