SPARECRUX is NOT an authorized distributor for OMRON

61F-HSL | OMRON | HIGH SENSITIVE LEVEL SWITCH , 220V AC

₹ 18,049.05

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

61F-HSL

Fabricant d'équipement d'origine

OMRON

Description
Specification Value
Type of Product Floatless Switch Super High Sensitivity Type 61F-HSL
Model No 61F-HSL AC100
Output AC 220 V 5A (Resistive Load), AC 220 V 2A (Inductive Load Cosφ=0.4)
Type Variable Type For Ultra-High Sensitivity
Power Consumption 3.2 or less
Rated Voltage AC 100 or 200V 50 / 60Hz (shared) V
Monotaro ID 38969192
Operation Ambient Temperature -10~+55℃
Insulation Resistance 100 or more (with DC 500 V Mega) MΩ
Withstand Voltage AC2000V 50/60Hz 1min
Ambient Humidity to Use 45～85%RH
Mechanical Life 5 Million Times or More
Return Resistance between Electrodes (Ω) (recommended value) Operating Resistance Between Electrodes + 2.5Ω Or More
Operating Resistance between Electrodes (Ω) (recommended value) 0-5M (Variable)
Current between Electrodes DC about 1 mA or less
Voltage between Electrodes 13 V DC or less
Electrical Life (Rated Load) 500,000 times or more
Allowable Voltage Fluctuation 85 to 110%
