SPARECRUX is NOT an authorized distributor for SIEMENS

6ES7 323-1BL00-0AA0 | SIEMENS | Digital Module

₹ 30,400.00

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

6ES7 323-1BL00-0AA0

Fabricant d'équipement d'origine

SIEMENS

Description
Brand Siemens
Module Type Digital I/O (16 DI / 16 DO)
Supply Voltage (DC) 24 V :contentReference[oaicite:0]{index=0}
Permissible Supply Voltage Range 20.4 … 28.8 V DC :contentReference[oaicite:1]{index=1}
Current from Load Voltage L+ (no load) Max. 80 mA :contentReference[oaicite:2]{index=2}
Current from Backplane Bus 5 V Max. 80 mA :contentReference[oaicite:3]{index=3}
Power Loss (typical) 6.5 W :contentReference[oaicite:4]{index=4}
Number of Digital Inputs 16 :contentReference[oaicite:5]{index=5}
Number of Digital Outputs 16 :contentReference[oaicite:6]{index=6}
Output Current per Output (rated) 0.5 A :contentReference[oaicite:7]{index=7}
Total Output Current Capacity 4 A :contentReference[oaicite:8]{index=8}
Input Delay (0 → 1 or 1 → 0) Min 1.2 ms / Max 4.8 ms :contentReference[oaicite:9]{index=9}
Cable Length (unshielded / shielded) 600 m / 1,000 m :contentReference[oaicite:10]{index=10}
Dimensions (W × H × D) 40 × 125 × 120 mm :contentReference[oaicite:11]{index=11}
Weight ≈ 260 g :contentReference[oaicite:12]{index=12}
Isolation & Protection Optically isolated inputs & outputs; galvanic separation between channels & backplane bus :contentReference[oaicite:13]{index=13}
SIEMENS

6ES7 323-1BL00-0AA0 | SIEMENS | Digital Module

₹ 30,400.00
Brand Siemens
Module Type Digital I/O (16 DI / 16 DO)
Supply Voltage (DC) 24 V :contentReference[oaicite:0]{index=0}
Permissible Supply Voltage Range 20.4 … 28.8 V DC :contentReference[oaicite:1]{index=1}
Current from Load Voltage L+ (no load) Max. 80 mA :contentReference[oaicite:2]{index=2}
Current from Backplane Bus 5 V Max. 80 mA :contentReference[oaicite:3]{index=3}
Power Loss (typical) 6.5 W :contentReference[oaicite:4]{index=4}
Number of Digital Inputs 16 :contentReference[oaicite:5]{index=5}
Number of Digital Outputs 16 :contentReference[oaicite:6]{index=6}
Output Current per Output (rated) 0.5 A :contentReference[oaicite:7]{index=7}
Total Output Current Capacity 4 A :contentReference[oaicite:8]{index=8}
Input Delay (0 → 1 or 1 → 0) Min 1.2 ms / Max 4.8 ms :contentReference[oaicite:9]{index=9}
Cable Length (unshielded / shielded) 600 m / 1,000 m :contentReference[oaicite:10]{index=10}
Dimensions (W × H × D) 40 × 125 × 120 mm :contentReference[oaicite:11]{index=11}
Weight ≈ 260 g :contentReference[oaicite:12]{index=12}
Isolation & Protection Optically isolated inputs & outputs; galvanic separation between channels & backplane bus :contentReference[oaicite:13]{index=13}
