6ES7223-1PM22-0XA0 | SIEMENS | Digital Input Output

₹ 57,000.00

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

6ES7223-1PM22-0XA0

Fabricant d'équipement d'origine

SIEMENS

Description
Model Number 6ES7223-1PM22-0XA0
Product Type Digital I/O Module, EM 223
System Compatibility SIMATIC S7-200, only for S7-22X CPU
Digital Inputs (DI) 32, 24 V DC, sink/source
Digital Outputs (DO) 32 relay outputs, 2 A per output
Supply Voltage (DC, Load Voltage L+) 24 V DC (permissible range: 5 V to 30 V DC) :contentReference[oaicite:0]{index=0}
AC Load Voltage L1 230 V AC (permissible range: 5 V to 250 V AC) :contentReference[oaicite:1]{index=1}
Input Current From backplane bus 5 V DC: max 205 mA; from external 24 V DC supply: max 128 mA :contentReference[oaicite:2]{index=2}
Power Loss (typical) ≈ 13 W :contentReference[oaicite:3]{index=3}
Switching Capacity (Relays) Resistive: 2 A per output; Inductive: ≤ 0.75 A per output; Lamp load: AC 200 W, DC 30 W :contentReference[oaicite:4]{index=4}
Number of Operating Cycles 10,000,000 mechanical cycles; 100,000 electrical at rated load :contentReference[oaicite:5]{index=5}
Cable Length Shielded max 500 m; Unshielded max 150 m :contentReference[oaicite:6]{index=6}
Dimensions (W × H × D) 196 × 80 × 62 mm :contentReference[oaicite:7]{index=7}
Weight ≈ 580 g :contentReference[oaicite:8]{index=8}
SIEMENS

6ES7223-1PM22-0XA0 | SIEMENS | Digital Input Output
