SPARECRUX is NOT an authorized distributor for FESTO

7960 | FESTO | Solenoid Valve MFH-3-1/2-S

₹ 5,353.29

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

7960

Fabricant d'équipement d'origine

FESTO

Description

Feature Specification
Valve function 3/2-way, closed, monostable
Type of actuation Electric
Construction width 52 mm
Standard nominal flow rate (DIN 1343) 3700 l/min
Pneumatic working port G1/2
Operating voltage Via solenoid coil, must be ordered separately
Operating pressure -0.095 MPa ... 1 MPa (-0.95 bar ... 10 bar)
Design Poppet seat
Type of reset Mechanical spring
Approval c UL us - Recognized (OL)
Degree of protection IP65
Nominal size 14 mm
Grid dimension 69 mm
Exhaust-air function With flow control option
Sealing principle Soft
Mounting position Optional
Manual override Detenting
Type of piloting Pilot actuated
Pilot air supply External
Flow direction Reversible
Symbol 00992879
Lap Underlap
Pilot pressure 0.1 MPa ... 0.8 MPa (1 bar ... 8 bar)
b value 0.3
Switching time off 90 ms
FESTO
