SPARECRUX is NOT an authorized distributor for FESTO

8047614 | FESTO | Quarter Turn Actuator DFPD-20-RP-90-RD-F04

₹ 5,357.60

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

8047614

Fabricant d'équipement d'origine

FESTO

Description

Feature Specification
Size of Valve Actuator 20
Flange Hole Pattern F04
Swivel Angle 90°
End-Position Adjustment Range at 0° -5° ... 5°
End-Position Adjustment Range at Nominal Swivel Angle -5° ... 5°
Shaft Connection Depth 12 mm
Fitting Connection Standard ISO 5211
Mounting Position Optional
Mode of Operation Double-acting
Design Rack and pinion
Closing Direction Closes to the right
Symbol 00991265
Valve Connection Standard VDI/VDE 3845 (NAMUR)
Connection Point for Positioner & Sensor VDI/VDE 3845 size AA 1
Device Type (VDMA 66413) Safety device
Safety Integrity Level (SIL) SIL 2 (Low Demand), Up to SIL 3 (redundant), SIL 1 (High Demand)
Certified Safety Standards ISO 13849, IEC 61508
Safety-Related Product Use SRP/CS up to SIL 2 (Low Demand), SIL 1 (High Demand), SIL 3 redundant
Burst Pressure 24 bar
Operating Pressure 0.2 MPa ... 0.8 MPa (2 bar ... 8 bar / 29 psi ... 116 psi)
Nominal Operating Pressure 0.55 MPa (5.5 bar / 79.75 psi)
Maritime Classification See certificate
CE Mark EU Explosion Protection Directive (ATEX)
UKCA Marking UK EX instructions
