SPARECRUX is NOT an authorized distributor for FESTO

8820 | FESTO | Solenoid Valve JMFH-5-1/8

₹ 3,120.48

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

8820

Fabricant d'équipement d'origine

FESTO

Description

Property Value
Valve function 5/2 bistable
Type of actuation Electric
Construction width 26 mm
Standard nominal flow rate (DIN 1343) 600 l/min
Pneumatic working port G1/8
Operating voltage Via solenoid coil (to be ordered separately)
Operating pressure 0.15 MPa ... 0.8 MPa / 1.5 bar ... 8 bar
Design Poppet seat
Approval c UL us - Recognized (OL)
Degree of protection IP65
Nominal size 5 mm
Grid dimension 27 mm
Exhaust-air function With flow control option
Sealing principle Soft
Mounting position Optional
Manual override Detenting
Type of piloting Pilot actuated
Flow direction Non-reversible
Symbol 00995754
Lap Underlap
Max. switching frequency 25 Hz
Switching time (reversal) 10 ms
Max. positive test pulse (0 signal) 2200 µs
Max. negative test pulse (1 signal) 3700 µs
Characteristic coil data See solenoid coil (to be ordered separately)
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating/pilot medium Lubricated operation possible (then always required)
Corrosion resistance class (CRC) 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Storage temperature -20 °C ... 60 °C
Media temperature -10 °C ... 60 °C
Ambient temperature -5 °C ... 40 °C
Product weight 260 g
Electrical connection Via F coil (to be ordered separately)
Type of mounting With through-hole
Pilot exhaust port 82 M5
Pilot exhaust port 84 M5
Pneumatic connection, port 1 G1/8
Pneumatic connection, port 2 G1/8
Pneumatic connection, port 3 G1/8
