SPARECRUX is NOT an authorized distributor for FESTO

This product has been discontinued, and manufacturer warranty or support may no longer be available.

9310 | FESTO | Round Cylinder DGS-12-25-P-A

₹ 3,040.00

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

9310

Fabricant d'équipement d'origine

FESTO

Description
Feature Specification
Stroke 25 mm
Piston diameter 12 mm
Piston rod thread M6
Cushioning Elastic cushioning rings/plates at both ends
Mounting position Optional
Mode of operation Double-acting
Piston-rod end Male thread
Design Piston, Piston rod
Position detection Via proximity switch
Symbol 00991217
Variants Piston rod at one end
Operating pressure 0.12 MPa ... 1 MPa
Operating pressure 1.2 bar ... 10 bar
Operating pressure 17.4 psi ... 145 psi
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium Lubricated operation possible (lubricated operation always required if used)
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20 °C ... 80 °C
Impact energy in end positions 0.07 J
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 51 N
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 68 N
Moving mass for 0 mm stroke 531 g
Product weight 1459 g
Type of mounting With through-hole, via female thread
Pneumatic connection G1/8
