SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

This product has been discontinued, and manufacturer warranty or support may no longer be available.

A9N1P25C | SCHNEIDER ELECTRIC | Acti9 xC60 MCB, 1-Pole, 25A, C-Curve, 10kA Breaking Capacity

₹ 507.30

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

A9N1P25C

Fabricant d'équipement d'origine

SCHNEIDER ELECTRIC

Description

Series Acti9 xC60
Part Code A9N1P25C (1P = 1‑pole, 25 A rated current)
Tripping Curve C‑curve (magnetic trip ~5–10× In)
Rated Breaking Capacity 15 kA at 220–240 V AC (Icu per IEC 60947‑2)
15 kA at 12–48 V DC
6 kA at 60 V DC
Rated Operational Voltage (Ue) 220–240 V AC (50/60 Hz)
12–48 V DC
60 V DC
Rated Insulation Voltage (Ui) 500 V AC; Impulse withstand 6 kV
Mounting DIN-rail, clip-on; reversible line/load wiring
Dimensions (HxWxD) ~85 mm H × 18 mm W × 77.5 mm D; weight ~115 g
Durability 20,000 mechanical cycles; 10,000 electrical cycles
Ambient Operating Temp –30 °C to +70 °C
Compliance IEC 60947‑2 and EN 60898‑1; Green Premium, RoHS/REACH certified
Isolation Capability Suitable as isolator per IEC standards
