A9N4P32C | SCHNEIDER ELECTRIC | Acti9 xC60 4‑Pole 32 A C‑Curve Miniature Circuit Breaker

₹ 2,717.95

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

A9N4P32C

Fabricant d'équipement d'origine

SCHNEIDER ELECTRIC

Description
Manufacturer Schneider Electric (Acti9 xC60 Series)
Device Type Miniature Circuit Breaker, 4‑Pole, C‑Curve
Rated Current (In) 32 A
Trip Curve C‑Curve (thermal‑magnetic)
Rated Voltage (Ue) 220–240 VAC, 50/60 Hz; 380–415 VAC; suitable for DC up to 60 V
Breaking Capacity (Icn / Icu) 10 kA @ 240/415 VAC (IEC 60898‑1); up to 15 kA Icu @ 380–415 VAC (IEC 60947‑2); 6 kA @ DC
Service Breaking Capacity (Ics) ≈ 7.5 kA @ 380–415 VAC; 6 kA @ DC
Utilisation Category Category A (IEC 60947‑2); Limitation Class 3 (IEC 60898‑1)
Isolation Capability Suitable for isolation per IEC 60947‑2
Contact Indication Yes – ON/OFF position indicator
Connections Biconnect terminals: up to 25 mm² flexible & 35 mm² rigid
Wire stripping length ~13 mm
Mounting Clip-on 35 mm DIN rail; 72 mm width (4 modules × 18 mm)
Dimensions (H × W × D) 85 × 72 × 77.5 mm
Weight ≈ 0.415 kg
Durability Mechanical: 20,000 cycles; Electrical: 10,000 cycles
Tightening Torque 3.5 N·m
Protection Rating IP20; Pollution degree 3; Overvoltage category IV
Operating Temperature −30 °C to +70 °C
Storage Temperature −40 °C to +85 °C
Standards & Certifications IS/IEC 60898‑1; EN/IEC 60947‑2; RoHS; Green Premium
