SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

This product has been discontinued, and manufacturer warranty or support may no longer be available.

C60H2P16AC | SCHNEIDER ELECTRIC | Acti 9 C60H 2‑Pole Miniature Circuit Breaker, 16 A, C‑Curve, AC 415 VAC

₹ 1,156.15

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

C60H2P16AC

Fabricant d'équipement d'origine

SCHNEIDER ELECTRIC

Description
Manufacturer Schneider Electric (Acti 9 C60H Series)
Device Type Miniature Circuit Breaker (MCB), 2‑Pole
Rated Current 16 A
Tripping Curve C‑Curve (thermal‑magnetic)
Rated Operational Voltage (Ue) 415 VAC / 50‑60 Hz
Breaking Capacity (Icu) 10 kA @ 440 VAC; up to 15 kA @ 415 VAC (IEC 60947‑2)
Service Breaking Capacity (Ics) ≈ 75 % of Icu (≈ 7.5–11 kA)
Insulation Voltage (Ui) 500 VAC
Impulse Withstand Voltage (Uimp) 6 kV
Mounting 35 mm DIN rail, fixed mounting
Terminal Type Tunnel‑type terminals, up to 16 mm² flexible or 25 mm² solid conductor, tightening torque ~2.0–2.5 Nm
Durability Mechanical: 20,000 cycles; Electrical: ~3,000 cycles (DC), higher at AC
Polarisation & Isolation Positive break indication, padlockable in OFF position
Operating Range −25 °C to +70 °C (operation); −40 °C to +85 °C (storage)
Weight ≈ 0.24 kg
Standards & Certifications IEC/EN 60947‑2, UL 1077/A600, CCC; Pollution degree 3; Overvoltage category IV
Unit Width 2‑module (18 mm pitch)
