SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

LA1KN04 | SCHNEIDER ELECTRIC | TeSys K - Auxiliary contact block - 4 NC - screw-clamps terminals

₹ 1,240.00

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

LA1KN04

Fabricant d'équipement d'origine

SCHNEIDER ELECTRIC

Description
Range of product TeSys K
Product or component type Auxiliary contact block
Device short name LA1KN04
Pole contact composition 4 NC (Normally Closed)
Contact operation Instantaneous
Connections – terminals Screw clamp terminals, flexible/solid cable up to 4 mm²
Rated operational voltage (Ue) ≤ 690 V AC (≤ 400 Hz)
Rated insulation voltage (Ui) 690 V IEC, 600 V UL/CSA, 750 V VDE
Conventional free-air thermal current (Ith) 10 A @ ≤ 50 °C
Rated making capacity (Irms) 110 A @ ≤ 690 V AC
Short-time rating 80 A (1 s); 60 A (500 ms); 110 A (100 ms)
Associated fuse rating 10 A gG ≤ 690 V
Minimum switching current 5 mA @ 17 V
Insulation resistance > 10 MΩ
Tightening torque 1.3 N·m (Philips No 2)
Mounting location Front mounting
Dimensions (H×W×D) 30 mm × 38 mm × 35 mm
Product weight ≈ 0.045 kg
Protection class IP2x (VDE 0106)
Ambient air temp (operation / storage) −25…50 °C / −50…80 °C
Operating altitude Up to 2000 m without derating
Standards & approvals EN/IEC 60947‑5‑1; UL508; CSA C22.2 No 60947‑5‑1; BS 5424; VDE 0660; JIS C8201‑5‑1
Certifications UL, CSA, CB, CCC, CE, UKCA
Protective treatment TC (Thermal treatment)
Sustainability status Green Premium, RoHS & REACh SVHC compliant
