SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

This product has been discontinued, and manufacturer warranty or support may no longer be available.

LC1D40B7 | SCHNEIDER ELECTRIC | Contractor 600VAC 40AMP IEC + Option

₹ 30,709.70

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

LC1D40B7

Fabricant d'équipement d'origine

SCHNEIDER ELECTRIC

Description
Product or Component Type IEC Contactor, TeSys D / Deca, non‑reversing, 3P (3 NO)
Device Short Name LC1D
Rated Operational Current
(AC‑3 / AC‑1 at ≤60 °C)		 40 A (AC‑3); 60 A (AC‑1) @ ≤440 VAC
Poles 3‑pole (3 NO)
Motor Ratings (AC‑3)
(at 50 Hz / 60 Hz)		 30 HP @ 460–480 VAC; 30 HP @ 575–600 VAC; various kW: up to 30 kW at 660–690 VAC; 18.5 kW @ 380–400 VAC; etc.
Control Circuit Voltage (Uc) 24 VAC, 50/60 Hz
Auxiliary Contacts 1 NO + 1 NC mechanically linked
Utilisation Categories AC‑1, AC‑2, AC‑3, AC‑3e, AC‑4
Insulation / Operational Voltages Ui: 690 V IEC; 600 V UL/CSA; Uimp: 8 kV; Overvoltage Category III
Control Terminal Capacity 1–4 mm² (rigid/flexible) via screw‑clamp terminals
Power Terminal Capacity 2.5–25 mm² (up to 35 mm² depending on application) via screw terminals/screw‑clamp
Tightening Torque Control: ~1.7 N·m; Power: ~5 N·m (or up to ~8 N·m for EverLink connectors)
Operating Speed (make/brake) Opening: 4–19 ms; Closing: 12–26 ms
Mechanical Durability 6 million operations
Maximum Operating Rate 3600 cycles/hour @ 60 °C
Safety Reliability (B10d) Nominal load: ~1.37 M cycles; Mechanical: ~20 M cycles (EN/ISO 13849‑1)
Minimum Switching (Signal) Capability ≥ 5 mA; ≥ 17 V
Power Dissipation / Inrush Hold-in: ~13 VA (60 Hz), ~15 VA (50 Hz); Inrush: ~140 VA (60 Hz), ~160 VA (50 Hz); Dissipation/pole: ~2.4 W (AC‑3)
Standards & Certifications IEC 60947‑4‑1 / IEC 60947‑5‑1, UL 508, CSA C22.2 No 14, CCC, GOST, RINA, DNV, Lloyd’s, UKCA, etc.
Protection Rating IP20 (front face)
Ambient Operating Temperature –40 °C … +60 °C (derating up to 70 °C)
Storage Temperature –60 °C … +80 °C
Dimensions (H×W×D) ~122 × 75 × 120 mm
Weight ~1.4 kg
