SPARECRUX is NOT an authorized distributor for SMC CORPORATION

SY5120-4DZ-01 | SMC CORPORATION | 2 Way Single Solenoid Valve 220Vac 1/8

₹ 2,992.50

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

SY5120-4DZ-01

Fabricant d'équipement d'origine

SMC CORPORATION

Description
Specification Detail
Model SY5120-4DZ-01
Series SY5000
Valve Type 5-Port, 2-Position, Single Solenoid
Function / Actuation Single Solenoid with Internal Pilot
Fluid Air
Operating Pressure Range Internal-pilot: 0.1 – 0.7 MPa
External-pilot: −100 kPa to 0.7 MPa
External pilot (pilot pressure): 0.25 – 0.7 MPa :contentReference[oaicite:0]{index=0}
Effective Area / Cv Body ported: 10.6 mm² (Cv ≈ 0.59); Base mounted: 12.6 mm² (Cv ≈ 0.7) :contentReference[oaicite:1]{index=1}
Rated Voltages Available 3, 5, 6, 12, 24 V DC; 100, 110, 200, 220 VAC :contentReference[oaicite:2]{index=2}
Response Time At 0.5 MPa, without indicator light & surge voltage suppressor: ≤ 32 ms :contentReference[oaicite:3]{index=3}
Ambient & Fluid Temperature Up to 50 °C :contentReference[oaicite:4]{index=4}
Voltage (in this listing) 220 VAC (≈ 230 VAC) :contentReference[oaicite:5]{index=5}
Port Size 1/8″ (Thread Rc) :contentReference[oaicite:6]{index=6}
Electrical Entry DIN terminal with connector :contentReference[oaicite:7]{index=7}
Manual Override Non-locking push type :contentReference[oaicite:8]{index=8}
Extra Features Indicator light & surge voltage suppressor included :contentReference[oaicite:9]{index=9}
