VHS40-04 | SMC CORPORATION | Port Lock Out VHS Hand Valve

₹ 4,215.84

Garantie

Nous offrons une garantie d'un an à compter de la date d'achat pour les produits neufs. De plus, les articles excédentaires ou d'occasion bénéficient d'une garantie de 30 jours .

Livraison et expédition

Nous traitons les commandes sous 5 à 7 jours ouvrés . Les options d'expédition varient selon la destination, avec suivi fourni. L'expédition internationale est disponible, les droits de douane étant à la charge du client.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Numéro de pièce du fabricant (MPN)

VHS40-04

Fabricant d'équipement d'origine

SMC CORPORATION

Description
Feature Details
Series / Model VHS40-04
Valve Type Pressure Relief 3-Port Valve, Single Action with Locking Holes
Port Sizes 1/4″, 3/8″, 1/2″, (varies with thread type: Rc, NPT, G) :contentReference[oaicite:0]{index=0}
Thread Standards Rc, NPT, G types available :contentReference[oaicite:1]{index=1}
Operating Pressure Range 0.1 to 1.0 MPa :contentReference[oaicite:2]{index=2}
Proof Pressure 1.5 MPa :contentReference[oaicite:3]{index=3}
Ambient & Fluid Temperature Range -5 °C to +60 °C (no freezing) :contentReference[oaicite:4]{index=4}
Handle / Bonnet Material Flame-resistant PBT (resin) or Aluminum versions available :contentReference[oaicite:5]{index=5}
Body / Bonnet Color / Handle Color Body: white; Handle: red (standard) :contentReference[oaicite:6]{index=6}
Flow / Cv Characteristics Higher flow in later designs; e.g. VHS40-04-D has up to ~88% increased flow over previous generation :contentReference[oaicite:7]{index=7}
Weight ≈ 0.247 kg for resin handle version (body size AC40) :contentReference[oaicite:8]{index=8}
SMC CORPORATION

VHS40-04 | SMC CORPORATION | Port Lock Out VHS Hand Valve

₹ 4,215.84
Feature Details
Series / Model VHS40-04
Valve Type Pressure Relief 3-Port Valve, Single Action with Locking Holes
Port Sizes 1/4″, 3/8″, 1/2″, (varies with thread type: Rc, NPT, G) :contentReference[oaicite:0]{index=0}
Thread Standards Rc, NPT, G types available :contentReference[oaicite:1]{index=1}
Operating Pressure Range 0.1 to 1.0 MPa :contentReference[oaicite:2]{index=2}
Proof Pressure 1.5 MPa :contentReference[oaicite:3]{index=3}
Ambient & Fluid Temperature Range -5 °C to +60 °C (no freezing) :contentReference[oaicite:4]{index=4}
Handle / Bonnet Material Flame-resistant PBT (resin) or Aluminum versions available :contentReference[oaicite:5]{index=5}
Body / Bonnet Color / Handle Color Body: white; Handle: red (standard) :contentReference[oaicite:6]{index=6}
Flow / Cv Characteristics Higher flow in later designs; e.g. VHS40-04-D has up to ~88% increased flow over previous generation :contentReference[oaicite:7]{index=7}
Weight ≈ 0.247 kg for resin handle version (body size AC40) :contentReference[oaicite:8]{index=8}
